Stone Engraving Machine JK-1215

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1429437

• Place of Origin:

  China
• Name： Stone Engraving Machine JK-1215
  Note： JK-1215 Stone Engraving Machine
  Main application profession: The engraving machines are professionally used to engrave marble,granite,limestone,sandstone and so on hard material.The machine can engrave letters and relief designs.
  ◆Matches with the German double nut and ball bearing guide screw.
  ◆Adopts straight line guide rail. The load-bearing surface with straight line guide rail is a surface contact and the life is 2200 times longer than ordinary rails. Its precision keeps high even with long time use.
  ◆Uses high speed drive motor. Its speed is enhanced nearly 2 meters higher than original type.
  ◆X axis uses the popular dustproof structure, which guarantee long-term performance characteristic.
  ◆Memory to insure the processing point when the blade is broken or postpone situation.
  ◆With good compatibility. This machine can work with many programs,such as,Type3/artcam/castmate/proe/
  Corelerow/CAD/CAM.The machine can do fine relief,2D and 3D products.
  ◆Big power water cooled frequency spindle motor,which can ensure to work on hard material.

  Technical parameter:
  MODLE
  JK-1215
  Work dimensions
  1200 x 1500 x 80mm
  Body dimensions
  1500 x 1900 x 1500mm
  Z-axis working area
  80mm
  Max. Feeding height
  120mm or bigger
  Cut thickness of material
  40mm
  Max. Speed
  6000mm/min
  Working speed
  0 - 4000mm/min
  Mechanical precision
  0.01mm
  Software
  Artcam, Artcut, Type3 software
  Max. Power consumption
  1800W
  Power source
  AC 220/50Hz
  Driver type
  stepper motor
  Spindle
  2.2KW variable speed, water-cooled
  Spindle speed
  0 - 24,000rpm
  Blade diameter
  1 - 6mm
  Control system
  NCSTUDIO or DSP
  Command
  HPGL,G code, u00, mmg, plt
