CNC Stone Engraving Machine JK-1224/1218/1212

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1426229

• Place of Origin:

  China
• Name： CNC Stone Engraving Machine JK-1224/1218/1212
  Note： CNC Stone Engraving Machine JK-1224/1218/1212

  Usage: can be used to engrave and cut various stone materials, like marble,granite,sandstone,limestone.
  Machine features:

  Particular style, competent for elaborate engraving and cutting.
  2.2KW water-cooled spindle motor.
  The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.
  Be compatible with type 3, Artcut, Artcam software.
  Memory to ensure the processing point when the blade is broken or postpone stitution. Specific saving mode of different points.

  Technical parameter:

  MODLE
  JK-1212
  JK-1218
  JK-1224

  Work dimensions
  1200 x 1200 x 80mm
  1200 x 1800 x 80mm
  1200 x 2400 x 80mm

  Body dimensions
  1500 x 1550 x 1500mm
  1500 x 2200 x 1500mm
  1500 x 2800 x 1500mm

  Z-axis working area
  80mm
  80mm
  80mm

  Max. Feeding height
  120mm or bigger
  120mm or bigger
  120mm or bigger

  Cut thickness of material
  40mm
  40mm
  40mm

  Max. Speed
  6000mm/min
  6000mm/min
  6000mm/min

  Working speed
  0 - 4000mm/min
  0 - 4000mm/min
  0 - 4000mm/min

  Mechanical precision
  0.01mm
  0.01mm
  0.01mm
  Software
  Artcam, Artcut, Type3 software
  Artcam , Artcut, Type3 software
  Artcam, Artcut, Type3 software
  Power source
  AC 220/50Hz
  AC 220/50Hz
  AC 220/50Hz

  Driver type
  stepper motor
  stepper motor
  stepper motor
  Spindle
  2.2KW variable speed, water-cooled
  3KW variable speed,water-cooled
  3KW variable speed, water-cooled
  Spindle speed
  0 - 24,000rpm
  24,000rpm
  24,000rpm
  Blade diameter
  1 - 6mm
  1 - 6mm
  1 - 6mm
  Control system
  NCSTUDIO
  NCSTUDIO
  NCSTUDIO
  Command
  HPGL,G code, u00, mmg, plt
  HPGL,G code, u00, mmg, plt
  HPGL,G code, u00, mmg, plt
